LH Series of motor aging testing line
UPDATE:2015-4-20 9:26:52 FROM:http://www.wx-ytjx.com

 This motor aging test line is suitable for running_in of the dynamo brush of vacuum cleaner, electric motor, and food crashing machine, first it works under a low pressure power for a period of time, and then switch to a rated voltage automatically, this is to increase the touch area between the electric brush and the commutator, thus to develop the motor operation quality and to reduce the noises.

 Features: adopts of rotary design, the trying out parts entrance and the finished part exit are in the same port, it adopts of continuous variable speed transmission, which if there is exist of voltage, it will convert automatically and contains of electric transfer device, equipped with voltage reducing transformer, noise reduction cabin and exhaust device, equipped with power and control screen, simple to clamping, it also has first trying out current and rated current setting. Technical parameters: supply voltage.


Main products technical features and parameters

序号

Nr.

名称

Item

单位

Unit

LH-120

LH-150

1

工位数

Amount of work positions

piece

120

150

2

工位节距

Work position pitch

mm

200

200

3

最大工件直径

Maximum part diameter to be processed

mm

180

180

4

单件工件功率

Single part power

kw

1.5

1.5

5

最高温升

Maximum temperature raising

≤60

≤60

6

总功率

General power


54

63

7

外形尺寸(**)

External dimension

(L*W*H)

m

12*2*2

15*2*2

8

重量

weight

kg

3000

3500

Note: Special requirement on process and production are welcome, by according to  customer requirement, we can design and manufacture the machine individually.
